Kaplan Hydro Turbine with Stainless Steel 0Cr13Ni14Mo Blades 2-50MW Rated Power and Water Cooled Hydropower Solution
Productdetails:
| Merknaam: | Wawushan |
| Certificering: | ISO9001 |
| Modelnummer: | ZDJ502-202501 |
Betalen & Verzenden Algemene voorwaarden:
| Minimum Order Quantity: | 1 |
|---|---|
| Prijs: | 50000-100000 |
| Packaging Details: | Export |
| Delivery Time: | 6 Months |
| Payment Terms: | L/C |
| Supply Ability: | 100 Units Per Year |
|
Gedetailleerde informatie |
|||
| Onderhoud: | Laag tot gemiddeld, met verstelbare messen voor eenvoudig onderhoud | Koelmethode: | Watergekoeld |
|---|---|---|---|
| Generatorvoltage: | met een vermogen van niet meer dan 10 kW | Kosten: | Betaalbaar |
| Nominaal vermogen: | 2-50MW | Blades materiaal: | Roestvrij staal 0Cr13Ni14Mo |
| Hoofdbereik: | 2 tot 70 meter | Hubmateriaal: | Koolstofstaal |
| Markeren: | Stainless Steel 0Cr13Ni14Mo Blades Kaplan Hydro Turbine,2-50MW Rated Power Hydropower Turbine,Water Cooled Hydroelectric Turbine |
||
Productomschrijving
Kaplan Hydro Turbine with Stainless Steel Blades
The Kaplan Hydro Turbine is an advanced hydro power generator engineered for exceptional performance and efficiency across various hydroelectric applications. Designed to harness flowing water energy for clean, renewable electricity generation, this turbine offers reliable operation for small to medium-scale projects with rated power capacity from 2 MW to 50 MW.
Advanced Design & Construction
Featuring a robust 0.7-meter diameter runner, the turbine efficiently converts water's kinetic energy into mechanical energy. The blades are crafted from high-quality stainless steel 0Cr13Ni14Mo, providing excellent corrosion resistance, high strength, and durability for long service life in varying water conditions.
The carbon steel hub offers strong structural support, withstanding intense mechanical stresses during operation. Combined with a water-cooled system that effectively dissipates heat, this turbine ensures stable performance under continuous load conditions while leveraging natural resources sustainably.
Key Features
- High-quality Stainless Steel 0Cr13Ni14Mo blades for superior durability and corrosion resistance
- Flexible installation options: Bulb, Pit, or Tube Type configurations
- Vertical water inlet design for optimal water flow efficiency
- 6300V generator voltage suitable for various hydro power applications
- Cost-effective solution for reliable hydro power generation
- Efficient design maximizing energy output from available water resources
- Integrated hydraulic turbine generator system for seamless operation
- Ideal for sustainable and renewable energy projects
Technical Specifications
| Runner Weight | 2-50T |
| Cooling Method | Water Cooled |
| Head Range | 2 to 70 Meters |
| Material | Stainless Steel |
| Runner Diameter | 0.7 M |
| Voltage | 400V |
| Guide Vane Material | Stainless Steel/Cast Iron |
| Generator Voltage | 6300V |
| Water Inlet | Vertical |
Application Scenarios
The Wawushan Kaplan Hydro Turbine (Model ZDJ502) is ideal for diverse hydroelectric applications, particularly small to medium-scale power plants where water flow and head conditions match operational requirements. Its installation flexibility makes it adaptable to various site conditions including river diversions, small dams, and irrigation canals.
Typical applications include remote rural electrification projects, hydroelectric stations near river basins, and renewable energy initiatives aimed at reducing carbon footprints. Suitable for communities seeking sustainable power solutions, industries requiring reliable off-grid electricity, and government green energy development projects.
Customization Options
We offer comprehensive customization services to meet specific hydraulic power needs. Customization includes material selection (stainless steel 0Cr13Ni14Mo blades, carbon steel hub, stainless steel/cast iron guide vanes), and configuration adjustments within the 2-50MW rated power range.
Order Information: Minimum order quantity 1 unit, price range $50,000-$100,000, delivery time approximately 6 months, flexible payment terms including L/C options. Annual supply capacity: 100 units.
Technical Support & Services
Our dedicated technical support team provides comprehensive assistance throughout your turbine's lifecycle. Services include installation and commissioning guidance, routine maintenance programs, troubleshooting, remote monitoring, and diagnostic analysis.
We offer operational staff training, genuine spare parts supply, and upgrade solutions to enhance performance and adapt to evolving energy requirements. Our experienced engineers ensure optimal performance and reliability through prompt, knowledgeable support.
